KATO HD30V5 Mini Excavator

$0.00 AUD
GST is included in price. Shipping calculated at checkout.

Cab Style: Choose an option

Cab Style: Choose an option
4 Post Canopy
Air Conditioned Cabin

KATO IHI Mini Excavators 3.2 Tonne Class

All New V5 Generation Zero Tail Swing Mini Excavator

  • Operating Weight -  4 Post Canopy 3105 kg/ Air Cab 3255kg
  • Yanmar 3TNV88 Engine
  • 42L Fuel tank capacity
  • Swinging Boom (L/R) 80 degree / 50 degree
  • 3000mm - Max. Digging depth
  • 5190mm - Max. Digging radius
  • 4720mm - Max. Digging height
  • 3390mm - Max. Dumping height
  • Powerful digging force 29.1kN (2970kgf)
  • Three pump hydraulic system
  • Corrosion free resin fuel tank
  • 4 posts ROPS canopy as standard (Cabin option)
  • Easy maintenance with wide opening engine covers
  • Rubber tracks
  • Removable counterweight
  • Hammer/Auger piping standard
  • 3 Years/3000 Hours Warranty

  • Newly designed operator’s space
  • Zero tail swing
  • Easy maintenance
  • Low fuel consumption
  • Powerful digging & quick response

  • ROPS/FOPS Certified

  • All-lever lock
  • Neutral engine-start
  • Auto-parking brake in swing & traction motors

  • Large covers for easier access


Kato's V5 Line features wide-opening access panels and large compartments for working around the engine, hydraulics etc.

V5 Excavators are built on some of the Industry's strongest and most stable track frames, maximising job-site safety and minimising equipment repairs.

Kato's V5 line features highly responsive pilot controls and easy to read instrument panels, all within the most comfortable cabs on the market.

The Kato 30V5 Excavator manoeuvers in the tightest spaces with a zero-tailswing design.

Air conditioned ROPS/FOPS enclosed cab is also an available option on the HD30V5.

For Pricing, complete the below form or Click Here to call our KATO specialists on 0459 WAREHOUSE. (That's 0459 927 346)

Package Variants
Cab Style

4 Post Canopy, Air Conditioned Cabin
