Digga PDH3 HALO auger drive combo package mini excavator up to 4T
Purchase any Digga PDH3 Earth Drill Combo Package and get *FREE FREIGHT!
The Digga PDH3 Earth Drill with HALO is suitable for mini excavators up to 4.0 tonnes, with flow rates of 45 to 75 Lpm.
Perfect for:
Airman AX33U/6A, AX38U/6A
Bobcat E32
Case CX33C, CX37C Canopy, CX37C Cab
Caterpillar 303E CR, 303.5E CR
Eurocomach ES35.2ZT
Hitachi ZX33U-5, ZX38U-5
Hyundai R35Z-9
JCB 8030ZTS, 8035ZTS
Kobelco SK30SR-6, SH35SR-6
Komatsu PC35MR-5
Kubota KX033-4, U35-4, KX040-4
New Holland E33C, E37C Canopy
Takeuchi TB235, TB138FR
Volvo ECR35D, ECR40D
Wacker Neuson EZ28VDS Canopy
Yanmar Vio30-6B, Vio35-6B
Yuchai YC35-8, YC35SR
PROUDLY PRODUCED AND MANUFACTURED IN AUSTRALIA
Please Provide the Make and Model of Your Machine in the "Special Instructions For Seller" Section Upon Checkout.
**More hitches are available on request, including Single Pin, Loose Double Pin and Cradle hitches but may incur a surcharge. Please contact us for more details if your machine isn't listed above.
Choose your package from the Drop Down Menu above.
Choosing your teeth and pilots:
Multi Facet Tungsten (MFT): Best all rounder; suitable for hard ground conditions including clay.
Earth/Rock Combo (RC): suitable for harder ground conditions including fracturable rock, asphalt and concrete.
Dedicated Rock (DR): suitable for fracturable and non fracturable rock.
What is HALO
Highly visible indicator
Halo features recessed high accuracy inclination green and red LED indicators, which can be clearly seen in daylight. With Halo, there in no need for an in-cab display screen, and no need to take your eyes off the job to realign your auger.
No setup (battery option)
Halo can be connected to the in-cab cigarette lighter, or powered by a magnetised rechargeable battery which will last all day, and can be charged via USB or a 240V wall charger. The battery pack can be attached to the drive hood, frame, machine boom, or placed in-cab.
Set angle of inclination
The battery powered option features a 'zeroing' function which lets the operator set the angle of inclination with the press of a button. This feature is ideal for the installation of shade sails.
Technology
HALO utilises a microprocessor and 6 sensors to provide accurate readings to +/- 0.25 degrees - Even under heavy vibration. Effectively eliminating the need for a spotter with a spirit level. The dust/water proof LED ring is also recessed into the hood to protect it from knocks.
Durable Australian quality
HALO is proudly made in Australia, and has undergone 4 years of development & testing to ensure the unit works faultlessly, and is capable of enduring the rigors of our industry.
Digga PDH3 Earth Drill Specifications:
Torque Range: 1188 - 3544 Nm
Oil Flow Range: 45 - 75 Lpm
Oil Pressure Range: 60 - 240 Bar
Hub: 65mm Round
Auger Specifications:
Digga 100mm A4 Auger:
Overall Length 1250mm
65mm Round Hub
Padloc Lock-in Teeth
Digga 150mm A4 Auger:
Overall Length 1250mm
65mm Round Hub
Padloc Lock-in Teeth
Digga 200mm A4 Auger:
Overall Length 1250mm
65mm Round Hub
Padloc Lock-in Teeth
Digga 250mm A4 Auger:
Overall Length 1250mm
65mm Round Hub
Padloc Lock-in Teeth
Digga 300mm A4 Auger:
Overall Length 1250mm
65mm Round Hub
Padloc Lock-in Teeth
Digga 350mm A4 Auger:
Overall Length 1250mm
65mm Round Hub
Padloc Lock-in Teeth
Digga 450mm A4 Auger:
Overall Length 1250mm
65mm Round Hub
Padloc Lock-in Teeth
Digga 600mm A4 Auger:
Overall Length 1250mm
65mm Round Hub
Padloc Lock-in Teeth
Pick up available from Brisbane, Gold Coast, Sydney or Melbourne
We ship earthmoving attachments Australia wide. *FREE FREIGHT Terms can be found here.
PDH3 with |
200mm & 300mm, 200mm & 300mm + 1m Ext Bar, 200mm & 300mm + Battery Pack, 200mm & 300mm + 1m Ext Bar & Battery Pack, 300mm & 450mm, 300mm & 450mm + 1m Ext Bar, 300mm & 450mm + Battery Pack, 300mm & 450mm + 1m Ext Bar & Battery Pack, 350mm & 450mm, 350mm & 450mm + 1m Ext Bar, 350mm & 450mm + Battery Pack, 350mm & 450mm + 1m Ext Bar & Battery Pack, 150mm 250mm & 350mm, 150mm 250mm & 350mm + 1m Ext Bar, 150mm 250mm & 350mm + Battery Pack, 150mm 250mm & 350mm + 1m Ext Bar & Battery Pack, 100mm 200mm & 300mm, 100mm 200mm & 300mm + 1m Ext Bar, 100mm 200mm & 300mm + Battery Pack, 100mm 200mm & 300mm + 1m Ext Bar & Battery Pack, 200mm 300mm & 450mm, 200mm 300mm & 450mm + 1m Ext Bar, 200mm 300mm & 450mm + Battery Pack, 200mm 300mm & 450mm + 1m Ext Bar & Battery Pack, 300mm 450mm & 600mm, 300mm 450mm & 600mm + 1m Ext Bar, 300mm 450mm & 600mm + Battery Pack, 300mm 450mm & 600mm + 1m Ext Bar & Battery Pack |
---|---|
TEETH TYPE |
Multi Facet Tungsten, Earth/Rock Combo, Dedicated Rock |
